Brake discs
AC-1226688
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 51
Brake Disc Thickness [mm]: 10
Minimum Thickness [mm]: 8,4
Number of Holes: 5
Machining: High-carbon
Technical information: PRIME LINE - UV Coated
Centering Diameter [mm]: 67
Manufacturer: BREMBO
Brake Disc Type: Unvented
Outer Diameter [mm]: 280
Manufacturer: BREMBO
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1305688
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 45
Brake Disc Thickness [mm]: 24
Minimum Thickness [mm]: 22,4
Number of Holes: 5
Machining: High-carbon
Technical information: PRIME LINE - UV Coated
Centering Diameter [mm]: 67
Manufacturer: BREMBO
Brake Disc Type: internally vented
Outer Diameter [mm]: 307
Manufacturer: BREMBO
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1420264
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Width [mm]: 129,0
Thickness [mm]: 18,5
Height 1 [mm]: 70,1
Height 2 [mm]: 75,1
Wear Warning Contact: Excl. wear warning contact; prepared for wear indicator
Number of screws: 4
Supplementary Article/Supplementary Info 2: with caliper guide screws
Manufacturer: ATE
Inspection Tag: E1 90R-02A0335/0246; E1 90R-02A0739/0241
Brake system: Lucas / TRW
Manufacturer: ATE
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1555104
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Thickness [mm]: 16,2
Width 1 [mm]: 123,0
Height 1 [mm]: 47,9
Width 2 [mm]: 123,0
Height 2 [mm]: 46,7
Inspection Tag: E1 90R-02A0169/0175
Manufacturer: ATE
Manufacturer: ATE
Wear Warning Contact: Excl. wear warning contact; prepared for wear indicator
Brake system: ATE
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1306944
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Width [mm]: 129,0
Thickness [mm]: 18,5
Height 1 [mm]: 70,1
Height 2 [mm]: 75,1
Inspection Tag: E9 90R-02A1396/4270
Brake system: Lucas / TRW
Technical information: ATE Ceramic
Manufacturer: ATE
Wear Warning Contact: Excl. wear warning contact; prepared for wear indicator
Number of screws: 4
Supplementary Article/Supplementary Info 2: with caliper guide screws
Manufacturer: ATE
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1428944
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Thickness [mm]: 16,2
Width 1 [mm]: 123,0
Height 1 [mm]: 47,9
Width 2 [mm]: 123,0
Height 2 [mm]: 46,7
Wear Warning Contact: Excl. wear warning contact; prepared for wear indicator
Inspection Tag: E1 90R-02A0258/0176
Technical information: ATE Ceramic
Brake system: ATE
Manufacturer: ATE
Manufacturer: ATE
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1249264
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 50,8
Brake Disc Thickness [mm]: 10,0
Minimum Thickness [mm]: 8,4
Number of Holes: 5
Manufacturer: ATE
Manufacturer: ATE
Machining: High-carbon
Inner diameter [mm]: 155,0
Outer Diameter [mm]: 280,0
Bore Ø [mm]: 16,5
Centering Diameter [mm]: 67,0
Brake Disc Type: Unvented
Pitch Circle Ø [mm]: 112,0
Inspection Tag: E1 90R-02C0165/0797
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1605264
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 50,8
Brake Disc Thickness [mm]: 20,0
Minimum Thickness [mm]: 18,4
Number of Holes: 5
Machining: High-carbon
Manufacturer: ATE
Bore Ø [mm]: 16,5
Inspection Tag: E1 90R-02C0115/0799
Centering Diameter [mm]: 67,0
Outer Diameter [mm]: 300,0
Manufacturer: ATE
Pitch Circle Ø [mm]: 112,0
Brake Disc Type: ventilated
Inner diameter [mm]: 166,0
Used: : 03.2018-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1061264
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 45,1
Brake Disc Thickness [mm]: 24,0
Minimum Thickness [mm]: 22,4
Number of Holes: 5
Bore Ø [mm]: 16,5
Outer Diameter [mm]: 330,0
Inspection Tag: E1 90R-02C0115/0652
Machining: High-carbon
Centering Diameter [mm]: 67,0
Manufacturer: ATE
Manufacturer: ATE
Availability: Bargain Offer
Pitch Circle Ø [mm]: 112,0
Inner diameter [mm]: 151,4
Brake Disc Type: ventilated
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1461264
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 45,1
Brake Disc Thickness [mm]: 24,0
Minimum Thickness [mm]: 22,4
Number of Holes: 5
Brake Disc Type: ventilated
Pitch Circle Ø [mm]: 112,0
Manufacturer: ATE
Centering Diameter [mm]: 67,0
Inner diameter [mm]: 151,0
Manufacturer: ATE
Bore Ø [mm]: 16,5
Machining: High-carbon
Inspection Tag: E1 90R-02C0115/0656
Outer Diameter [mm]: 307,0
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-19181573
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 4. TÜV Rheinland ; Din ; Dot
Height [mm]: 50,5
Brake Disc Thickness [mm]: 10
Minimum Thickness [mm]: 8,4
Centering Diameter [mm]: 67
Manufacturer: TEXTAR
Inner diameter [mm]: 155,3
Manufacturer: TEXTAR
Supplementary Article/Supplementary Info 2: without wheel bearing; without wheel hub; without wheel studs
Hole Arrangement / Number: 05/06
Pitch Circle Ø [mm]: 112
Brake Disc Type: Unvented
Outer Diameter [mm]: 280
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Wear indicator
AC-19312773
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 1 pc
Location (Front/Rear): FRONT
Side (Left/Right): LEFT
Manufacturer:
Quality: 2. OEM/OES
Length 1 [mm]: 200
Length 2 [mm]: 475
Manufacturer: BREMBO
Manufacturer: BREMBO
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Wear indicator
AC-13312773
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 1 pc
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Manufacturer: BREMBO
Length [mm]: 642
Manufacturer: BREMBO
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1175554
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 4. TÜV Rheinland ; Din ; Dot
Height [mm]: 50,5
Brake Disc Thickness [mm]: 10
Minimum Thickness [mm]: 8,4
Number of Holes: 5
Inspection Tag: E1 90R-02C0100/1555
Outer Diameter [mm]: 280
Supplementary Article/Supplementary Info 2: without wheel bearing; without ABS ring
Manufacturer: DELPHI
Machining: Untreated
Centering Diameter [mm]: 67
Manufacturer: DELPHI
Brake Disc Type: Unvented
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1263504
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 45,2
Brake Disc Thickness [mm]: 24
Minimum Thickness [mm]: 22,4
Number of Holes: 5
Outer Diameter [mm]: 330
Centering Diameter [mm]: 67
Brake Disc Type: ventilated; internally vented
Pitch Circle Ø [mm]: 112
Manufacturer: BOSCH
Manufacturer: Bosch
Drill Ø, up to [mm]: 16,8
Availability: Bargain Offer
Machining: High-carbon
Used: : 06.2015-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1663504
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 50,6
Brake Disc Thickness [mm]: 20
Minimum Thickness [mm]: 18,4
Number of Holes: 5
Manufacturer: BOSCH
Outer Diameter [mm]: 300
Brake Disc Type: ventilated; internally vented
Pitch Circle Ø [mm]: 112
Machining: High-carbon
Centering Diameter [mm]: 67
Manufacturer: Bosch
Availability: Bargain Offer
Drill Ø, up to [mm]: 16,7
Used: : 06.2015-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1671124
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Width [mm]: 123,2
Thickness [mm]: 15,9
Height 1 [mm]: 46,3
Height 2 [mm]: 47,6
Supplementary Article/Supplementary Info 2: with damping washer
WVA Number: 25331
Inspection Tag: ECE-R90
Manufacturer: BOSCH
Manufacturer: Bosch
Used: : 06.2015-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1318304
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Width [mm]: 128,5
Thickness [mm]: 18,35
Height 1 [mm]: 70,8
Height 2 [mm]: 76,1
WVA Number: 25617
Manufacturer: Bosch
Inspection Tag: ECE-R90
Number of screws: 4
Manufacturer: BOSCH
Used: : 06.2015-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1506154
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): FRONT
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 45,2
Brake Disc Thickness [mm]: 24
Minimum Thickness [mm]: 22,4
Number of Holes: 5
Pitch Circle Ø [mm]: 112
Manufacturer: TRW
Brake Disc Type: ventilated
Availability: Bargain Offer
Inspection Tag: E1 90R-02 C0176/0615
Manufacturer: TRW
Outer Diameter [mm]: 307
Centering Diameter [mm]: 67
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1228814
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 50,6
Brake Disc Thickness [mm]: 20
Minimum Thickness [mm]: 18,4
Number of Holes: 5
Outer Diameter [mm]: 300
Manufacturer: TRW
Pitch Circle Ø [mm]: 112
Brake Disc Type: ventilated
Manufacturer: TRW
Centering Diameter [mm]: 67
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake discs
AC-1628814
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: 2 pcs
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Height [mm]: 50,5
Brake Disc Thickness [mm]: 10
Minimum Thickness [mm]: 8,4
Number of Holes: 5
Brake Disc Type: Unvented
Centering Diameter [mm]: 67
Manufacturer: TRW
Inspection Tag: E190R-02C0204/0525
Outer Diameter [mm]: 280
Manufacturer: TRW
Pitch Circle Ø [mm]: 112
Used: : 03.2018-
IMPORTANT! Specification: : Open / Close here!
Brake caliper repair kit
AC-1263828
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): REAR
Manufacturer:
Quality: 4. TÜV Rheinland ; Din ; Dot
Diameter [mm]: 34
Brake system: ATE
Manufacturer: ERT
Fitting Side: Rear Axle
Manufacturer: ERT
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake caliper repair kit
AC-1587610
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): REAR
Manufacturer:
Quality: 4. TÜV Rheinland ; Din ; Dot
Diameter [mm]: 12
Manufacturer: ERT
Brake system: ATE
Manufacturer: ERT
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-1042934
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): REAR
Manufacturer:
Quality: 2. OEM/OES
Width [mm]: 123,0
Thickness [mm]: 16,0
Height [mm]: 46,6
Manufacturer: TRW
Inspection Tag: E9 90R-02A0120/3972
Manufacturer: TRW
Wear Warning Contact: prepared for wear indicator
Manufacturer Restriction: ATE
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
Brake pads
AC-7205237
Model: 2 Gran Tourer Van (F46), 07.14-
Sales Unit: packing unit: set: 1 pc(s)
Location (Front/Rear): FRONT
Manufacturer:
Quality: 4. TÜV Rheinland ; Din ; Dot
Width [mm]: 148,3
Thickness [mm]: 19,2
Height [mm]: 70
Brake system: BOSCH
Manufacturer: ICER
Inspection Tag: E9 90R-01111/3152
Manufacturer: ICER
Used: : 07.2014-
IMPORTANT! Specification: : Open / Close here!
